DVP VB Claws Vacuum Pumps

Models : VB 315 │ VB 315 FLEXDRIVE

DVP VB Claws Vacuum Pumps

https://drive.google.com/drive/folders/1SBH_Np7w6HPDTOBg2-TbQdkg75z0bMIp?usp=sharing

DVP VB Claws Vacuum Pumps

‍

DVP VB series claws Vacuum pumps are designed for industrial processes requiring high pumping capacity, reliable Vacuum generation and consistent performance

‍

The VB 315 range is available in two configurations to meet specific operating requirements: the standard fixed-speed VB 315, delivering a nominal pumping speed of 315 m³/h at 50 Hz, and the variable-speed VB 315 FLEXDRIVE, designed to adapt to fluctuating vacuum demand.

‍

The VB 315 FLEXDRIVE operates over a speed range of 2,000 to 3,500 rpm, providing greater flexibility when vacuum requirements fluctuate throughout the production cycle

‍

Combining claw vacuum technology, high pumping capacity and operational flexibility, the DVP VB series offers an effective solution for industrial Vacuum applications, with configurations suited to different process requirements

‍

‍

Contact us

Availability:

In stock or 6 to 8 weeks depending on the version

Technical specifications of DVP VB claws Vacuum pumps

(Indicative data, tailored to your setup)

Technical Specifications DVP VB Claw Vacuum Pumps
Nominal Pumping Speed at 50 Hz Up to 380 m³/h
Ultimate Pressure Down to 165 mbar(a)
Motor Power at 50 Hz Up to 7.5 kW
Rotational Speed at 50 Hz 2,000 to 3,500 rpm
Sound Pressure Level at 50 Hz 71 to 74 dB(A)
Inlet Connection DN50
Discharge Connection DN40
Installed Motor Power 5.5 to 7.5 kW
Weight 297 to 305 kg
Electrical Supply Three-phase – VB 315: 230/400 V at 50 Hz, depending on configuration; FLEXDRIVE: 380–480 V, 50/60 Hz

Key benefits of DVP VB claw Vacuum pumps for your processes

  • High pumping capacity: up to 380 m³/h, to meet the needs of processes requiring high vacuum flow
  • Two operating configurations: VB 315 with fixed speed or VB 315 FLEXDRIVE with variable speed, allowing the solution to be tailored to the installation's requirements
  • Adaptability to process variations: the FLEXDRIVE operates within a range of 2,000 to 3,500 rpm, offering greater flexibility when vacuum demand fluctuates
  • High-efficiency drive systems: IE3 motor on the VB 315 and IE5 on the VB 315 FLEXDRIVE
  • Controlled noise level: 71 dB(A) at 50 Hz for the VB 315 and 74 dB(A) for the FLEXDRIVE, according to the UNI EN ISO 2151 standard

Typical industrial applications for DVP VB claws Vacuum pumps

‍

DVP VB claws Vacuum pumps combine high pumping capacity with fixed- or variable-speed operation to meet changing industrial vacuum requirements

‍
  • Vacuum gripping and handling
  • Packaging and wrapping machines
  • Workpiece holding and clamping
  • Automation and production lines
  • Processes with variable vacuum requirements
DVP VB Claws Vacuum Pumps

Why choose GEFI for your DVP VB claws vacuum pumps ?

GEFI provides technical expertise in the selection, sizing and integration of DVP VB claw Vacuum pumps, taking into account the required pumping speed, vacuum level and operating conditions of your industrial process.

A choice tailored to your process: select the fixed-speed VB 315 or the variable-speed VB 315 FLEXDRIVE based on your flow rate and vacuum level requirements

A complete and controlled installation: expert advice on necessary peripheral equipment and accessories, including suction filters, vacuum gauges, control valves, and non-return valves

Dedicated technical expertise: expert guidance on Vacuum pump sizing and integration to meet the specific requirements of your industrial application

With GEFI, you benefit from a tailored vacuum solution backed by industry expertise and a thorough understanding of your operational requirements
